210
Omnik
Procedure
1. Connect the wires for the cable connection as shown in the following diagram.
Solar-Log™ terminal strip connector RJ45 inverter
Terminal PIN
► 1 + ► PIN 3 TX+
► 3 GND ► PIN 7 GND
► 4 - ► PIN 6 TX-
2. Insert the RJ45 plug into any RJ45 socket on inverter 1.
3. Insert the terminal block connector into the Solar-Log™ RS485 socket
Connect the inverters to each other
•
Connect using a network cable (patch cable)
•
Where to connect: RJ45 socket outside the inverter
Procedure
1. Insert the RJ45 plug into any RJ45 socket on inverter 1.
2. Insert the other end of the wire into any RJ45 socket on inverter 2.
3. Connect the other inverters to each other in the same way.
