241
Q3
3. Terminate on the inverter in accordance with the manufacturer‘s handbook.
4. Close the inverter if no other inverters are to be connected.
5. Insert the terminal block connector into the Solar-Log™ RS485 socket.
Connect the inverters to each other
•
Connection in the master-slave data network using an 1:1 cable with M12 plug connector.
•
Sockets X6 and X7 are connected to each other electrically.
•
Where to connect: Round pin plug on the outside of the inverter.
Procedure
1. Insert the plug into the X6 socket on inverter 1.
2. Insert the other end of the wire into the X7 socket on inverter 2.
3. Connect the other inverters to each other in the same way.
4. Terminate the last inverter according to the manufacturer‘s instructions.
Allocate communication address
•
Setting: Using the inverter‘s control panel, parameter 89 in the communication menu.
Recommendation: Continuous numbering starting with 1.
Set this in the SSP address menu item.
•
Procedure: Start according to the inverter‘s instructions
Note
The mode Fixed cos Phi has to be set according to the manufacturer's specifications for all of the inver-
ters to use active and reactive power management.
