Solectria
Connect the inverters to each other
•
Connect using a network cable (patch cable)
•
Where to connect: RJ45 socket (RJ45 R and L) on the outside of the inverter,
Procedure
1. Insert the RJ45 plug into the free RJ45 socket on the first inverter.
2. Insert the other end of the wire into any RJ45 socket on inverter 2.
3. Connect the other inverters to each other in the same way.
4. Terminate the last inverter in accordance with the inverter instructions.
Caution
Every inverter has to have an unique ID number (address) between 1 and 16. Please contact Solectria
Renewables for support if you have inverters with the same ID number.
Only the manufacturer can change the ID numbers.
