Valenia
Connect the inverters to each other
The wiring is done using a
•
self-made connection cable and terminal block connector.
•
Where to connect: Terminal strip on internal interface card
Procedure
1. Open the inverter as shown in the inverter's instructions.
2. Connect terminals P, N and 0V of the first inverter 1 to the corresponding terminals on the next inverter.
3. Connect the other inverters to each other in the same way.
4. Terminate the last inverter in accordance with the manufacturer's specifications.
5. Address the individual inverters in accordance with the manufacturer's manual.
6. Close the inverter if no other inverters are to be connected.
7. Insert the terminal block connector into the Solar-Log™ RS485 socket.
Note
A maximum of 32 inverters can be connected per RS485 bus.
