Solar-Log™ PRO
Connectiondiagramfordifferentoperatingmodes
The meter connections are labeled IN (bottom) and OUT (top)
Solar-Log™ PRO1 Mod (RS485 or S0) connection assignments
► As consumption or sub-consumer meter Connection to the grid (IN) – connection for appliances
(OUT)
► As generator / production meter Connection for the production (IN) – connection to the
grid (OUT)
Solar-Log™ PRO1 Mod connection assignments (only RS485)
► As a consumption meter (bi-directional) Connection for grid (OUT) – connection to the house/
plant (IN)
(installation position according to the arrow system)
------------------------------------------------------------------
(Starting with rmware version 3.4.2, the metering direc
-
tion (report) for consumption meters in bi-direction mode
can be set in the Solar-Log™.)
► As a battery meter (bi-directional) Connection to the production/grid (IN) – connection to the
battery (OUT)
Cable connection via RS485:
Solar-Log™ terminal strip connector Solar-Log 50 Solar-Log™ PRO1 Mod
Terminal PIN
► 1 1 or 5 23 (A)
► 4 4 or 6 24 (B)
Note
If the meter is the last device on the bus, it has to be terminated at connection block 23 and 24 with a
resistor (120 ohm / 0.25W).
Note
The Inepro PRO1 Mod cannot be connected to the inverters with a single bus.
For this reason, use one RS485 connection for the inverters and one RS485 connection for the So-
lar-Log™ PRO1 Mod.
► A combination with a M&T sensor as well as with the Solar-Log™ PRO380 Mod and Solar-Log™
Pro380-CT in the same bus is possible.
Possible meter operating modes for the Solar-Log™ PRO1 Mod via RS485:
•
Battery meter (bi-directional)
•
Total plant meter
•
Sub-consumption meter
•
Consumption meter
•
Consumption meter (bi-directional)
•
Generator
