VARTA Battery System
Procedure for IP addresses assignment:
In addition to a static, fixed IP, a dynamic IP address can also be assigned.
Dynamic IP adress:
Both devices, the Solar-Log ™, and the VARTA battery system must be provided automatically to IP address (DHCP).
Static IP adress:
•
Please select an IP address with the same class C subnet as the Solar-Log™.
For example: The Solar-Log™ has the IP address 192.168.178.49.
The battery system in this case has to have a free IP address in the same range (from 192.168.178.1 to
192.168.178.254).
•
Procedure: Start according to the battery system‘s instructions.
Detection via the Solar-Log
™
WEB interface
•
For the device detection on the Solar-Log
™
select „VARTA:Industrial“ in the Network section from the Configu-
ration | Devices | Definition
menu.
•
Also select the proper interfaces for the meters as well as the inverters. Confirm the selection by clicking on
Save.
Detection from the Solar-Log 1200
When using the Solar-Log 1200, the detection can also be started from the display.
•
Select „VARTA:Industrial“ from the „Network“ interface for the detection.
•
Also select the proper interfaces for the meters as well as the inverters and then start the detection.
Note
Only one battery system can be connected to a Solar-Log™ device.
Note
If a Varta consumption meter is connected to the battery system, an additional consumption meter
(bi-direction meter) is detected and recorded by the Solar-Log™ when it is detected. (The consumption
meter is active after the detection.)
Note
The Varta Industrial battery system cannot be used with the Solar-Log 50.
