Staubli CS8C User Manual

CS8C © Stäubli 2009 – D28070504A
115 / 248
Chapter 6 - Operation
6.1. POWERING UP THE CONTROLLER
To start the controller, set the switch (1) to position "1" (figure 6.1).
Figure 6.1
See the Safety chapter 3.3 for the procedure to isolate the system from the electrical power supply.
When the electricity supply to the controller is switched on, the MCP screen and all the LEDs flash on and off.
Next, a "Stäubli CS8" message is displayed on the screen, and then the main menu is shown after about 2
minutes.
DANGER:
Before carrying out any work on the components inside the controller, it is essential
to set the master switch (1) to position "0".
DANGER:
When the master switch (1) is on "0", the cables and the filter located upstream from
the switch remain live.
1

Staubli CS8C Specifications

General

Brand	Staubli
Model	CS8C
Category	Controller
Language	English
