Position reading
The position reading is done with the e00CurrPos analog input. The position is in degrees, with an accuracy of
360/(4*e00Counts).
The encoder position is updated every 4ms. When a preset is done while the encoder is moving, it applies to the
start of the current 4ms time interval. The encoder position is updated only with the next time interval, where it is
assigned the preset position plus the encoder movement of the last 4ms. In that way, no encoder movement is
lost with the preset.
Position capture (latching)
Position capture is used to record the encoder position on a rising signal for a fast input, and then read the position
later.
Position capture procedure
:
• Activate the e00EnLatch digital output.
• On the next rising or falling signal for the fast input e00LatchSig, the encoder position is recorded in the
e00LatchPos analog input and the e00Latch digital input is activated to show that the capture has been
executed. The e00EnLatch Input/Output is then automatically deactivated.
The precision of the capture is less than one microsecond. It is possible to cancel a capture request at any time
by deactivating the e00EnLatch output.
Note:
The position capture is made:
- On the rising edge of the e00LatchSig signal if the e00LatchEdgFall digital output is set to
False.
- On the falling edge if the e00LatchEdgFall digital output is set to True.
It is possible to filter out bounds on the latch signal by specifying a filter delay in milliseconds
using the e00LatchFilter analog output: the latch is then effective only if the signal remains
stable during the specified time. The latched position is then always the position at the rising or
falling edge of the latch signal.
Errors
An encoder reading error is signalled by the e00HwErr digital input. If the encoder is rotating too fast, it is not
possible for the controller to know for certain how many rotations the encoder has made. In this case, the
e00OvsErr signal is activated. The maximum encoder speed is 7500 rpm.
Note:
When the encoder has moved by more than one turn, the system is able to detect its resolution
that is then written to the e00CountsMes analog input. If this resolution does not match the
specified resolution e00Counts, the encoder is in error and the e00CountsErr signal is
activated.
The e00PowerErr digital output is activated when the encoder power supply is not correct.
To reactivate the encoder after an error, it is necessary to reset it using the e00RstErr digital output.
CAUTION:
The internal encoder position counter uses only 32 bits. When the encoder position reaches
2 31*360/(4*e00Counts) degrees, an overshoot occurs and the position becomes -
2 31*360/(4*e00Counts).
No error is reported: The overshoot must be managed by software programming, either by
using a preset to avoid it, or by correcting the position with an offset of 2 32*360*4*e00Counts
degrees.
^
^
^

Staubli CS8C Specifications

General

Number of Axes	Up to 6
Programming Language	VAL3
Protection Class	IP 54
Humidity	5 to 95% non-condensing
Compatible Robots	Staubli robots
Communication Interfaces	Ethernet, Serial, Fieldbus
Safety	Safety PLC integration
Operating Temperature	0 to 45°C
Storage Temperature	-20°C to 60°C
