CS8C
© Stäubli 2009 –
D28070504A
239 / 248
Chapter 8 - Maintenance
DSI
advanced info
rmation
Common lin
es for all en
coders:
•1
3
V
power su
pply.
•D
S
I
.
•
Optical fiber.
•5
V
from
DSI
to encode
rs.
Individual lines:
•D
S
I
to encoder communication.
Figure
8.72
DSI
board's
D1
ON: Encode
r = OK
D2
ON: Thermo = OK
D3
Slow: Init. Fast. = OK
D0
ON: DSI =
OK
Transmit
Receive
Fiber in
Fiber out
Encoder
1
Encoder
2
Encoder
6
Optical fiber
5V
encoder
Common power supply
Individual comm
unication
channels
238
240
