Chapter 8 - Maintenance
Access to fan
s
The fan
2(
2
)
is accessed by removing the screws
(1)
holding the grille and the air filter in place.
The fan
3
(3)
for the
RPS
power supply can be
accessed by removing the
amplifier for joint
s
3-6
(see
pages
181
and
182
).
To remove it, take out the
2
screws
(4)
.
Figure
8.14
Figure
8.15
DANGER:
When fans are defect
ive, cooled part
s can be very hot.
4
2
Fan
2
4
3
Axis
3-6
Fan
3
178
