CS8C
© Stäubli 2009 –
D28070504A
197 / 248
Chapter 8 - Maintenance
8.7.2.2.
CS8C
FOR
RX160
ROBOTS
•
To access the connectors, remove the
ARPS
(3)
powe
r supply wires he
ld in place by
4
screws
(4)
(see chapte
r
8.6.2
) and the metal plate
(5)
holdin
g the socket and kept in pla
ce by
4
screws
(6)
.
Figure
8.35
•
Disconnect
the connec
tors
J1001
(1)
,
J1002
(2)
,
J1003
(3)
,
J1004
(4)
,
J1005
(5)
.
Figure
8.36
5
6
4
3
1
2
3
4
5
