© Stäubli 2009 –
D28070504A
CS8C
190 / 248
8.6.6.4.
ADVANCED INF
ORM
ATION
This output is a
24
VDC
signal.
When there is no fault (stat
us in control panel =
ON
)
SECTEUR_OK
signal is set to
24
V
.
When there is a fault (stat
us in control panel =
OFF
)
SECTEUR_OK
signal is set to
0V
.
Figure
8.28
RSI
AR
P
S
J104-
3
J104-
8
J1102-14
SECTEUR_OK-
J1102-6
SECTEUR_OK+
24V
GND
BRK-ON
Pin 8
ALIM-OK
24V1
24V1
24V2
13V
0 VDC
+
SECTEUR-OK
BRK-REL-EN
Pin 1
189
