© Stäubli 2009 –
D28070504A
CS8C
208 / 248
8.8.3.6.
CASE
5
•
If
D52
is off: See chapters
8.5,
8.6,
8.7
, pages
169,
176,
194
.
•
If
D49,
D50
and
D52
are On:
•
Check that
ST
ARC
board is operating (
see chapter
8.9
, pag
e
232
).
•
Change it if necessary.
•
Check wiring between
ST
ARC
J302
and
RSI
J100
.
•
Change the
RSI
.
Problem:
RSI
display is off,
no indication.
Solution:
?
207
209
