© Stäubli 2009 – D28070504A CS8C210 / 248
When switching on controller, the RSI display goes through intermediate steps where the 7-segment and
right point are alternatively flashing.
This sequence lasts approximately 2 minutes.
DISPLAY
APPEARANCE
STATUS
- E flashing The RSI board is waiting to be synchronised with the STARC board
- r flashing The STARC board is waiting to be synchronised with the computer
- 5 + pt left flashing Waiting for the "Safety" task to start
- (i) Waiting for the power supply to be switched on
