Chapter 4 - Installation
Figure 4.12
The length of the cables must be taken into account to facilitate maintenance.
Interconnection cable:
• Cable Ø: 25 mm
• Connector passage Ø: 90 mm
WMS cable:
• Cable Ø: 7 mm
• Connector passage Ø: 25 mm
71
25
73
32
52
74
55
43
