Waste System
The waste system is vertically aligned. Surgical fluid enters both canisters
through either a single-port or four-port manifold. Fluid from the small canister empties
into the large canister via a quarter turn drain valve. The large canister is tapered at the
bottom to allow connection directly to the waste coupler without any tubing needed.
Fluid leaves the coupling block and exits through the docking station’s external waste
hose.
Coupling
Block
Small
Canister
Large
Canister
In From
Manifold
In From
Manifold
To Docking
Station
Tank
Valve
5-7
