Stryker Neptune 2 - Separation of Large & Small Canister Assemblies

Separation of Large & Small Canister Assemblies
This procedure outlines how to separate the large and small canister assemblies. It
should be followed only after removing both assemblies together as described in the preceding
section. If you are only replacing the small canister, proceed to Small Canister Assembly (p.
2-35).
Caution: Ensure that the small canister is empty prior to step 1! Loosening the
seal nut and removing the fluid level transducer may cause fluid to leak from the
small canister if it is not empty.
1. Using an adjustable wrench, loosen the transducer seal nut (P/N 0702-001-225) (B)
on the large canister cap. This provides the tension relief required to remove the fluid
level transducer.
2. Carefully unthread and remove the fluid level transducer (P/N 702-1-880) (AN) from
the small canister cap assembly (P/N 702-1-200) (AM).
2-31
