4. Next, push the buttons next to the arrow icons (on the left side) to highlight the
LEVEL DATA menu and press OK to display the level data screen. (see figure 8)
ESC
OK
LEVEL DATA
CALIBRATE FLOAT
LEVEL SENSOR
Figure 8: Select the LEVEL DATA Menu
5. The level sensor data screen will display “APP” centered on the far right hand
portion of the screen. Press and hold the button at the upper right hand corner
until the screen displays DIAG. (see figure 9)
Figure 9: Hold Upper Right Hand Button
6-41
