Main Control Board
Component
Measurement
Location
Black
Lead
Red
Lead
Reading
Unit of
Measure
State
Main Control Board J8 on Connector Pin 1
Pin 2 0 Ohm
Connector removed, while
pressing button A
Pin 3 0 Ohm
Connector removed, while
pressing button B
Pin 4 0 Ohm
Connector removed, while
pressing button C
Pin 5 0 Ohm
Connector removed, while
pressing button D
Pin 6 0 Ohm
Connector removed, while
pressing pole up
Pin 7 0 Ohm
Connector removed, while
pressing pole down
Pin 8 0 Ohm
Connector removed, while
pressing volume reset
Pin 9 0 Ohm
Connector removed, while
pressing rank dump
Pin
10
0 Ohm
Connector removed, while
pressing vacuum system
Pin
11
0 Ohm
Connector removed, while
pressing smoke evacuator
Pin
12
n/a n/a n/a
Pin
13
n/a n/a n/a
Pin
14
n/a n/a n/a
