6-28
4. Measure and record the earth leakage in all combinations listed in table 6.5.5.
Analyzer Settings
Leakage Current Limit
Polarity Neutral
Normal Closed 20 < X < 300 uA
Reverse Closed 20 < X < 300 uA
Normal Open 30 < X < 1000 uA
Reverse Open 30 < X < 1000 uA
Table 6.5.5 Analyzer Settings and Leakage Current Limit for Docking Station
