6. In the DOCKING CONTROL menu, the OK button is used to cycle through
the different options.* For instance, when OFFLOAD is highlighted, pressing
OK will cycle between on and off. Continue to use the arrow buttons to
highlight, and the ok button to select in order to complete the required steps in
table 5.3, then proceed to step 7.
Step
Select Option
(Use Arrow Keys)
Change To
(Use OK Key)
Comments
6.1 Magnet On Magnet may already be on.
6.2 Diverter Large
6.3 Couplings Extending Wait until couplings read "EXTENDED" before proceeding.
6.4 Water On Press and Hold OK to fill large** canister to 2 liters.
6.5 Diverter Closed
6.6 Couplings Retracting Wait until couplings read "RETRACTED" before proceeding.
6.7 Magnet Off Rover should release from the docking station.
Table 6.3: Restoring the Prefill in the Canisters
* When used for the WATER option, the OK button must be held continuously to allow water to flow. The water flow will stop when
the OK button is released.
** If placing water into the small canister, it is ok to add two liters of fluid, as long as doing so will not overflow the tank.
DO NOT add
two liters if the small canister has more than two liters currently present. Cycling water on/off and on/off may break up remaining
debris in canister.
6-32
