Studer OnAir 2000M2 User Manual

OnAir 2000M2 Digital Mixing Console
4-6 Alignment SW V4.0 Date printed: 12.11.03
on the PCB), and the MIC GAIN trimmer potentiometer is adjusted to a
level just below the point where no more output level increase is meas-
ured.
If an other microphone is used, the appropriate input connector, jumper
settings and input signal level must be used.
OUTPUT LEVEL: After the MIC GAIN adjustment, the balanced TB mic output – available
at the XLR connector OUT (P3), or at the AMP connector TB OUT SYM
(P9) on the PCB – is adjusted with the OUTPUT LEVEL trimmer potenti-
ometer (RA2) to the desired nominal level.

Studer OnAir 2000M2 Specifications

General

Brand	Studer
Model	OnAir 2000M2
Category	Music Mixer
Language	English
