OnAir 2000M2 Digital Mixing Console
2-4 General SW V 4.0 Date printed: 12.11.03
Analog Outputs Analog output modules are available with balancing transformers or with electroni-
cally balanced outputs, XLR connectors.
Output level (transformer-balanced)
+4 to +24 dBu @ R
L
= 100 kΩ;
+4 to +23 dBu @ R
L
= 300 Ω
Output level (electronically balanced)
+4 to +23 dBu @ R
L
= 100 kΩ;
+4 to +22 dBu @ R
L
= 300 Ω
D/A converter 24 bit (Delta-Sigma, 128 × oversampling)
Dynamics typ. 101 dB (unweighted)
THD+N < –90 dB
FS
@ 1 kHz, –1 dB
FS
Frequency response ±0.2 dB
Output impedance < 40 Ω
Digital Outputs Digital output modules are equipped with two independent outputs according to the
AES/EBU standard (AES3-1992). On each of these outputs, the same signal is fed
to two XLR sockets with individual buffers.
Output level 2 to 5 V
Output impedance 110 Ω
Equalizer Treble control (High) 5 kHz/10 kHz: ±15 dB (depending on Customer Code setting; refer to 12.2.12)
Equalizer (Mid) 200 Hz to 10 kHz: ±15 dB
Bass control (Low) 200 Hz/400 Hz: ±15 dB
Crosstalk Attenuation
Between channels > 90 dB
Input fader attenuation > 100 dB
Power Supply Mains voltage 100 to 240 V, 50/60 Hz (auto-ranging)
Power consumption 150 VA typ. (OnAir 2000/24/4)
Redundant power supply available on request.
Weight OnAir 2000M2 6/4 34 kg
OnAir 2000M2 12/4 44 kg
OnAir 2000M2 18/4 55 kg
OnAir 2000M2 24/4 63 kg
Note: Depending on the application, the on-air mixing consoles can have differ-
ent configurations. For this reason the abovementioned values are applica-
ble only to a typical configuration; in an individual case, the values may
differ. We reserve the right to make changes as technological progress may
warrant.
