Date printed: 12.11.03 SW V 4.0 Monitoring 7-7
Note: Configuration of talkback and signaling is also possible for analog line or
digital inputs as well as for a TB mic input, as shown by the following
screenshots.
When installing an optional TB Mic Input module, two different cases
must be distinguished:
Console configuration TB Source Signaling
TB Mic Input module within channel configuration (e.g. input
module no. 13 of an 18-input-module console)
configurable configurable
TB Mic Input module outside channel configuration (e.g.
input module no. 13 of a 12-input-module console)
must be set
to CR, else
no function
don't care, no
signaling
available
