GTS Technical Manual
9. April 2021 Edition: V1.00/2021 6-5
Copyright © 2020, Diversey
06.14.24 dashboard - 3500µicro_V1.00.fm
6.2 Dashboard
6.2.2 Mounting of dashboard
Picture 6: Dashboard
• Position the dashboard.
• Connect all electrical connections to the dashboard.
• Position the dashboard onto the front hood.
Be cautious when mounting the dashboard as you can damage the
wires or the ribbon cables of the dashboard.
• Mount the 6 screws of the dashboard.
Make sure that you check the function of the stop actuator during
each visit as this is a security feature.
