5.2 Tank
5.2.5 Removing of tank
Picture 12: Recovery tank
• Remove all accessories and disconnect the hoses from the tank
cover (4134109).
• Remove the tank cover according to chapter REMOVING OF TANK
COVER.
• Remove the seat cover according to chapter REMOVING OF
DRIVER SEAT COVER.
• Remove the vacuum motor assembly according to chapter
REMOVING OF VAVCUUM MOTOR ASSEMBLY.
• Disconnect all plugs and connectors to the tank.
• Remove the 6 fixation screws (4109990) of the tank (4134108)
at the 2 supports (4131414).
Remarks
To reach the 6 fixation screws (4109990) of the tank (4134108) you
need to remove the batteries.
