GTS Technical Manual
9. April 2021 Edition: V1.00/2021 5-26
Copyright © 2020, Diversey
05.26.24 steering unit - front wheel - 3500µicro_V1.00.fm
5.4 Steering unit
5.4.6 Mounting of front wheel
Picture 36: Mounting front wheel
• Position the front wheel on the axle.
• Mount and tighten the screw and the washer.
Service
Lubricate the front wheel bearing with ball bearing grease (4039680).
Apply adhesive locking (4017370) on the hexagon screws.
