5.6 Tool lowering unit
5.6.2 Mounting of tool lowering unit
Picture 48: Tool lowering unit details
• Position the tool lowering unit under the machine and align
roughly with the screw mounting position.
Be aware of the weight of the tool lowering unit as it can fall down and
close.
Only work on the brush lowering unit, when the emergency stop
button is permanently engaged.
There is a risk of cutting / squeezing fingers seriously if caught in the
closing scissors mechanism of the tool lowering unit. Do not reach
into the open tool lowering unit when loosening the screws or trying
to lower it down!
Missteps can lead to personal injury and damage to the machine.
Picture 49: Tool lowering unit numbered
