GTS Technical Manual
9. April 2021 Edition: V1.00/2021 6-6
Copyright © 2020, Diversey
06.14.44 dashboard - connections - 2100µicro_4000_5000_3500µicro_V2.00.fm
6.2 Dashboard
6.2.3 Connections
Picture 7: Dashboard connections
Picture 8: Dashboard key switch
Please find description of the connections on the following table. The connections are
marked in the upper pictures (Picture: Dashboard connections and Dashboard key
switch) with numbers and the pin 1 of the connections is marked with a red dot.
