GTS Technical Manual
9. April 2021 Edition: V1.00/2021 4-3
Copyright © 2020, Diversey
04.1 AERO 3500µicro - technical data_V1.00.fm
4.2.3 Machine speed
4.2.4 Dimensions and weights
Pos. Unit Value
Transportation speed (km/h) 5.5
Cleaning speed (km/h) 5.5
Reverse speed (km/h) 2.7
Ramp max. cleaning (%) 2.0
Ramp max. transport (%) 10
Table 4: Machine speed
Pos. Unit Value
Dimensions L/W/H (mm) 1350/650/1280
Door pass through with (lifted up) side brush (mm) 650 (580)
Battery compartment L/W/H (mm) 390 x 500 x 280 (270)
Net weight without batteries; empty tank (kg) 181
Weight, ready to use (kg) 305
Max. floor pressure front (N/mm2) 0.41
Max. floor pressure rear (N/mm2) 0.71
Turn radius (between two walls) (mm) 1800
Wheel diameter traction (mm) 250
Wheel diameter front (mm) 200
Table 5: Dimensions and weights
