Taski AERO 3500 micro - Charger; Brush system

GTS Technical Manual
9. April 2021 Edition: V1.00/2021 4-6
Copyright © 2020, Diversey
04.1 AERO 3500µicro - technical data_V1.00.fm
4.2.6 Charger
4.2.7 Brush system
Pos. Unit Value
Primary (V) 100-240
Primary (Hz) 50-60
Secondary (V) 24
Secondary (A) 25
Protection class (BMS model) I
Approval CB/cUL/KC/RCM
Cable length/BMS cable (m) 5
Table 8: Charger
Pos. Unit Value
Main brush system (mm) 2 x 512 x 100
Main brush motor (W) 750
Main brush speed (hard floor/carpet) (rpm) 900/1250
Brush pressure max. (N/cm2) 0.43
Side brush system (mm) 300
Side brush motor (W) 60
Side brush speed (rpm) -
Side broom offset (mm) 100
Table 9: Brush system
