GTS Technical Manual
9. April 2021 Edition: V1.00/2021 5-18
Copyright © 2020, Diversey
05.24.17 driver seat - seat switch - 3500µicro_V1.00.fm
5.3 Driver seat
5.3.6 Mounting of seat switch
Picture 26: Seat switch unit
• Position the seat switch into the mounting hole.
• Connect the wires to the seat switch.
• Turn the seat switch set clockwise until it is fixated correctly.
• Position the cover.
• Position and tighten the two screws.
Picture 27: Mounting seat switch
• Place the driver seat onto the driver seat cover.
Make sure that you check the correct function of the seat switch
during each visit as this is a security feature.
