5.2 Tank
5.2.3 Removing of cleaning mode micro switch
Picture 9: Cleaning mode micro switch
• Remove the four screws (4122639) from the micro switch cover
(4134106).
• Disconnect the plug from the micro switch (4133638).
• Remove the screw (4070960) together with the washer
(4091230).
• Remove the micro switch (4133638).
