GTS Technical Manual
9. April 2021 Edition: V1.00/2021 5-15
Copyright © 2020, Diversey
05.24.16 driver seat - driver seat cover - 3500µicro_V1.00.fm
5.3 Driver seat
5.3.3 Removing of driver seat cover
Picture 20: Driver seat cover
Remarks
The driver seat (4132166) is constructed that you can move it around.
We advise to place it on a stable position, for example onto the floor
beside the machine.
• Place the driver seat on a stable position.
• Unlock the seat cover lock (4129284).
Picture 21: Removing driver seat cover
• Remove the driver seat cover (4131363) by lifting it up.
• According to what you need to exchange, remove the existing
parts from the driver seat cover and place it on the new one.
