Pos. Plug Description [plug] Pin Description [pin]
1 X1 Key switch 1 Plus (+) 24VDC from key switch
1 X1 Key switch 2 Not connected
2 X2 Charger communication 1 Information charge - yellow
2 X2 Charger communication 2 Information charged - green
2 X2 Charger communication 3 Information charge failed - red
2 X2 Charger communication 4 Immobilise OUT (Emergency loop)
2 X2 Charger communication 5 Immobilise IN (Emergency loop)
2 X2 Charger communication 6 GND
3 X3 Stop actuator 1 Emergency loop - IN
3 X3 Stop actuator 2 Emergency loop - OUT
4 X4 Start switch 1 Start IN
4 X4 Start switch 2 Start OUT
5 X5 Control unit 1 Emergency loop
5 X5 Control unit 2 Coding 1 (TASKI swingo 4000)
5 X5 Control unit 3 Coding 2 (TASKI swingo 5000)
5 X5 Control unit 4 Coding 3 (TASKI swingo 2100µicro)
5 X5 Control unit 5 Coding 4 (TASKI AERO 3500µicro)
5 X5 Control unit 6 Eeprom
6 X6 TASKI Bus 1 CAN_H
Table 1: Dashboard connections
