GTS Technical Manual
9. April 2021 Edition: V1.00/2021 6-8
Copyright © 2020, Diversey
06.14.44 dashboard - connections - 2100µicro_4000_5000_3500µicro_V2.00.fm
6 X6 TASKI Bus 2 CAN_L
6 X6 TASKI Bus 3 Plus (+) 24VDC
6 X6 TASKI Bus 4 GND
7 X20 Membrane keypad right 1 LED_Charge
7 X20 Membrane keypad right 2 LED_Charged
7 X20 Membrane keypad right 3 LED_Charge_Fail
7 X20 Membrane keypad right 4 LED_K
7 X20 Membrane keypad right 5 Not connected
7 X20 Membrane keypad right 6 Not connected
7 X20 Membrane keypad right 7 SCAN OUT 3
7 X20 Membrane keypad right 8 SCAN OUT 4
7 X20 Membrane keypad right 9 MUX OUT 0
7 X20 Membrane keypad right 10 MUX OUT 1
7 X20 Membrane keypad right 11 MUX OUT 2
7 X20 Membrane keypad right 12 MUX OUT 3
7 X20 Membrane keypad right 13 MUX OUT 4
7 X20 Membrane keypad right 14 MUX OUT 5
7 X20 Membrane keypad right 15 SCAN OUT 3
7 X20 Membrane keypad right 16 TASTER IN 1
7 X20 Membrane keypad right 17 TASTER IN 2
Pos. Plug Description [plug] Pin Description [pin]
Table 1: Dashboard connections
