GTS Technical Manual
9. April 2021 Edition: V1.00/2021 6-9
Copyright © 2020, Diversey
06.14.44 dashboard - connections - 2100µicro_4000_5000_3500µicro_V2.00.fm
7 X20 Membrane keypad right 18 TASTER IN 3
7 X20 Membrane keypad right 19 TASTER IN 0
7 X20 Membrane keypad right 20 TASTER IN 0
7 X20 Membrane keypad right 21 SCAN OUT 4
7 X20 Membrane keypad right 22 Not connected
7 X20 Membrane keypad right 23 Not connected
7 X20 Membrane keypad right 24 Not connected
8 X21 Membrane keypad left 1 SCAN OUT 0
8 X21 Membrane keypad left 2 SCAN OUT 1
8 X21 Membrane keypad left 3 SCAN OUT 2
8 X21 Membrane keypad left 4 MUX OUT 0
8 X21 Membrane keypad left 5 MUX OUT 1
8 X21 Membrane keypad left 6 MUX OUT 2
8 X21 Membrane keypad left 7 MUX OUT 3
8 X21 Membrane keypad left 8 MUX OUT 4
8 X21 Membrane keypad left 9 MUX OUT 5
8 X21 Membrane keypad left 10 Not connected
8 X21 Membrane keypad left 11 SCAN OUT 0
8 X21 Membrane keypad left 12 SCAN OUT 1
8 X21 Membrane keypad left 13 SCAN OUT 2
Pos. Plug Description [plug] Pin Description [pin]
Table 1: Dashboard connections
