GTS Technical Manual
9. April 2021 Edition: V1.00/2021 6-23
Copyright © 2020, Diversey
06.20.27 charger - connections - 2100µicro_3500µicro_V2.00.fm
Pos. Plug Description [plug] Pin Description [pin]
1 Battery supply - Battery - (Minus, black wiring)
2 Battery supply - Battery + (Plus, red wiring)
3 Main power 1 Main power
3 Main power 2 Main power
4 Communication to electronics 1 GND
4 Communication to electronics 2 Plus (+) 12VDC from electronics
4 Communication to electronics 3 Not connected
4 Communication to electronics 4 Battery detection
4 Communication to electronics 5 Battery change detection
4 Communication to electronics 6 I2C: SCL
4 Communication to electronics 7 I2C: SDA
4 Communication to electronics 8 Battery change detection input reset
5 Communication to dashboard 1 Not connected
5 Communication to dashboard 2 Not connected
5 Communication to dashboard 3 Immobiliser (internal switch)
5 Communication to dashboard 4 Immobiliser (internal switch)
5 Communication to dashboard 5 GND
5 Communication to dashboard 6 Information charge failed - red
5 Communication to dashboard 7 Information charge - yellow
5 Communication to dashboard 8 Information charged - green
Table 3: Charger connections
