05.30.27 tool lowering unit - linear drive - 3500µicro_V1.00.fm
Picture 63: Mounting linear drive detail
• Mount the two retaining washer.
• Thread in the cable and place.
Remarks
Make sure that you fixate the cable with cable ties.
When fixating the cable of the linear drive, make sure the necessary
movement is allowed.
• Mount the tool lowering unit according to chapter MOUNTING OF
TOOL LOWERING UNIT.
• Mount the brush unit according to chapter MOUNTING OF BRUSH
DRIVE.
• Mount the seat cover according to chapter MOUNTING OF SEAT
COVER.
