GTS Technical Manual
9. April 2021 Edition: V1.00/2021 5-52
Copyright © 2020, Diversey
05.32.23 drive unit - drive unit - 3500µicro_V1.00.fm
Picture 76: Removing drive unit
• Push the drive unit to the front to slide it out of the chassis.
Picture 77: Removing drive unit compl
• Remove the drive unit.
• According to what you need to exchange, remove the existing
parts from the drive unit and place it on the new one.
