Remarks
To mount the pressure springs, you need to tilt the brush deck to the
back side, then to the front side. This will allow to place the two
pressure springs in to the defined position.
Picture 91: Mounting pressure spring
Make sure that the wires cannot be damaged during movements of
the brush unit.
