Picture 104: Mounting belt pulley
Remarks
Ensure that the cables of the motor are positioned that they lead
directly to the connection block.
Adjustment
Shorten the brush motor cables to approx 200mm. This will ensure a
sufficient length to the connection block.
Make sure that the cables of the brush motor do not interfere with the
movement of the tool lowering unit.
