139
MN F09 002 US  DOK-383E  Issue/Rev. 3.65 (02/24)
MultiFlow  Configuration of the MultiFlow
No.
Name
Seal
K
Factory
Setting
Meaning
3.1.6.9.7.3.2
Sensor type
M
2
1 - Digital NC
Type of sensor
contact
1 – Digital NC contact
2 – Digital NO contact
3 – Namur NC contact
4 – Namur NO contact
3.1.6.9.7.3.3
Alarm event
M
2
0 (no)
Additional alarm message at change of status. Must
be acknowledged by the user.
3.1.6.9.7.4
In-line valve
S/M
3.1.6.9.7.4.1
Start sensor pos.
M
2
0
Position of the first sensor
3.1.6.9.7.4.2
Sensor type
M
2
1 - Digital NC
Type of sensor
contact
1 – Digital NC contact
2 – Digital NO contact
3 – Namur NC contact
4 – Namur NO contact
3.1.6.9.7.4.3
Alarm event
M
2
0 (no)
Additional alarm message at change of status. Must
be acknowledged by the user.
3.1.6.9.7.5
Cabinet door left
S/M
3.1.6.9.7.5.1
Start sensor pos.
M
2
0
Position of the first sensor
3.1.6.9.7.5.2
Sensor type
M
2
1 - Digital NC
Type of sensor
contact
1 – Digital NC contact
2 – Digital NO contact
3 – Namur NC contact
4 – Namur NO contact
3.1.6.9.7.5.3
Alarm event
M
2
0 (no)
Additional alarm message at change of status. Must
be acknowledged by the user.
3.1.6.9.7.6
Cabinet door right
S/M
3.1.6.9.7.6.1
Start sensor pos.
M
2
0
Position of the first sensor
3.1.6.9.7.6.2
Sensor type
M
2
1 - Digital NC
Type of sensor
contact
1 – Digital NC contact
2 – Digital NO contact
3 – Namur NC contact
4 – Namur NO contact
3.1.6.9.7.6.3
Alarm event
M
2
0 (no)
Additional alarm message at change of status. Must
be acknowledged by the user.
3.1.6.9.7.7
Handbrake
S/M
3.1.6.9.7.7.1
Start sensor pos.
M
2
0
Position of the first sensor
3.1.6.9.7.7.2
Sensor type
M
2
1 - Digital NC
Type of sensor
contact
1 – Digital NC contact
2 – Digital NO contact
3 – Namur NC contact
4 – Namur NO contact
3.1.6.9.7.7.3
Alarm event
M
2
0 (no)
Additional alarm message at change of status. Must
be acknowledged by the user.
3.1.6.9.8
Ext. parameter
protection
S/M
2
0 (no)
Activates extended parameter protection. When
active, sensor interface parameters can be changed
only when the electronic seal is broken.
9.3.1.13 IO interface
No.
Name
Seal
K
Factory
Setting
Meaning
3.1.6.0
IO interface
3.1.6.0.1
Use IO
M
2
0 (no)
Activation of the optional IO expansion
3.1.6.0.2
IO node
M
2
0
Node number of the IO expansion, if the latter has
been activated.
