TechnipFMC Sening MultiFlow - Epe2; Sensor Interface; Sensors

MN F09 002 US  DOK-383E  Issue/Rev. 3.65 (02/24)
MultiFlow  Address and contact details
300
Sening® is a registered trademark of FMC Technologies
EPE2
No.
Name
Seal
K
Factory
Setting
Meaning
3.1.6.8
EPE2
(version 5.00 and higher)
3.1.6.8.1
Use of EPE2
M
2
0 (no)
Activation of EPE2 required for optional residue
discharge
3.1.6.8.2
EPE2 node
M
2
5
Node number of EPE2 when activated
3.1.6.8.3
EPE2 interval
M
2
600ms
EPE2 request interval. Used to trigger EPE2 inactivity
monitor.
3.1.6.8.4
Invert
M
2
0 (No)
Invert the input conditions sent from the EPE2
(including when an EPE2-A1 is used). Short-circuit
and interruption are not affected by this.
Sensor interface
No.
Name
Seal
K
Factory
Setting
Meaning
3.1.6.9
Sensor interface
3.1.6.9.1
Use SI
S/M
2
0 (no)
Activation of the optional sensor module
3.1.6.9.2
SI node
S/M
2
0
Node number of sensor module when activated.
3.1.6.9.3
Compartment number
S/M
2
1
Number of compartments to monitor.
(1 .. 20)
3.1.6.9.4
Request interval
2
60s
Average request interval without connecting external
power supply.
(0 .. 21600s)
3.1.6.9.5
Transmission delay
S/M
2
50ms
Interface-end telegram delay on CAN bus. (0 ..
255ms)
3.1.6.9.6
Trigger interval
S/M
2
5s
Interval before watchdog is triggered (inactivity
detection). (0 .. 60)
Sensors
No.
Name
Seal
K
Factory
Setting
Meaning
3.1.6.9.7
Sensors
3.1.6.9.7.1
Dome cover
S/M
3.1.6.9.7.1.1
Start sensor pos.
M
2
0
Position of the first sensor
3.1.6.9.7.1.2
Sensor type
M
2
1 - Digital NC
Type of sensor
contact
1 – Digital NC contact
2 – Digital NO contact
3 – Namur NC contact
4 – Namur NO contact
3.1.6.9.7.1.3
Alarm event
M
2
0 (no)
Additional alarm message at change of status. Must
be acknowledged by the user.
3.1.6.9.7.2
API coupling
S/M
3.1.6.9.7.2.1
Start sensor pos.
M
2
0
Position of the first sensor
3.1.6.9.7.2.2
Sensor type
M
2
1 - Digital NC
Type of sensor
contact
1 – Digital NC contact
2 – Digital NO contact
3 – Namur NC contact
4 – Namur NO contact
3.1.6.9.7.2.3
Alarm event
M
2
0 (no)
Additional alarm message at change of status. Must
be acknowledged by the user.
3.1.6.9.7.2.4
Delay time
M
2
0s
Delay time for detecting a status change during
delivery
3.1.6.9.7.3
Foot valve
S/M
3.1.6.9.7.3.1
Start sensor pos.
M
2
0
Position of the first sensor
