9.11 Notes on Parameter Checks
Parameter checking has been designed to be more operator-friendly. If
errors are found during parameter checking, then an alarm message
appears on the screen which enables the operator to print a parameter
report.
The parameter report summarizes all the settings which conflict with the
defined boundary conditions.
A parameter report may appear as follows:
Explanation:
Parameter 3.1.6.1:
the global node
number must not be
greater than “31”.
Parameter 3.3.2.2,
parameter (35.11).71:
Compensation cannot
be provided with an
inactive temperature
sensor!
In the MultiFlow the following parameter dependencies are currently
checked:
3188 + Overfill Prev. Frequency Input
3335 Ext. Prod. Sensor Yes
The overfill prevention and also the external level
sensor for the additive tank use digital input no. 4
3141 Operation Mode TMC
3152 + No. Of Discharges 2
For operation with on-board computers (TMC or
EMIS = OBC) only 1 liquid product per receipt can
be discharged.
3141 Operation Mode TMC
3161 Global Node No. 0
For operation with on-board computers (TMC or
EMIS = OBC) the CAN bus must be activated for
communication (node number greater than 0)
3141 Operation Mode
3161 Global Node No.
3163 OBC Node
For operation with the EMIS interface (OBC) the
node numbers of MultiFlow and OBC must be
different.
Illegal Value
3187 Hose Set
Only one particular number / combination of
discharge paths is permissible.
Report date
Version
Meter desig.
: 18.08.1998 14.45
: 2.02[2.00]UK
: PI-ME 97
------------------------------------------
Recalibration needed!
------------------------------------------
Range Error
3161 Global node no. 32
(35.11.) Heating oil EL
------------------------------------------
Parameter Conflict
3322 + Sensor inactive Yes
.71 + Compensation Yes
-End of printout-
