Pulse inputs
No.
Name
Seal
K
Factory
Setting
Meaning
3.3.1
Pulse counter
3.3.1.1
Pulse Rating
Cal.
1
1
Number of pulses per liter (see preliminary certificate
and measuring system name-plate).
3.3.1.2
Max. Return Volume
Cal.
1
8 (liter)
Permissible return volume up to which no error is
displayed, in liters.
3.3.1.3
Max. Error Pulses
Cal.
1
2
No of permissible error pulses.
PTB recommendation: The set value should
correspond to twice the pulse rating
(i.e. in this case 2 liters)
3.3.1.4
Sensor Type
Cal
1
2 (PNP)
Selection of the pulse transmitter type.
1: NPN
2: PNP (default)
3: THS (Sening GMVT 704/805/1004)
IMPORTANT: The type coding is offset by one place
from the program version 1.01.!
3.3.1.5
Min. Flow Rate
Cal.
1
20 (L/Min.)
Minimum flow rate during discharge. Flow rates below
this limit will switch off pulse error detection and the
discharge will be interrupted after 30 seconds.
0: A value of 0 liters/minute will switch off this
function.
3.3.1.6
Direction of rotation
Cal.
1
0 (default)
Direction of rotation of the measurement system:
0: default
1: reversal of the direction of rotation
Temperature Sensor
No.
Name
Seal
K
Factory
Setting
Meaning
3.3.2
Temperature sensor
3.3.2.1
Temp. Offset
Cal.
1
Preliminary
certificate
Figure for temperature offset according to
W&M certificate.
0
Offset 0°C
-
0
Device size
Setting for temperature offset.
IMPORTANT: The parameter is set during the
preliminary test and cannot be
changed.
0
Offset 100°C
-
0
Device size
Setting for temperature offset.
IMPORTANT: The parameter is set during the
preliminary test and cannot be
changed.
3.3.2.2
Disable sensor
Cal.
1
0 (No)
(De)activates the MultiFlow temperature
measurement.
IMPORTANT: With an inactive sensor no
compensation and no mass
computation can be carried out!
IMPORTANT: If no sensor is connected, the
temperature inputs must be fitted with
a jumper.
