TechnipFMC Sening MultiFlow - Form Description; Product Definition

MN F09 002 US  DOK-383E  Issue/Rev. 3.65 (02/24)
MultiFlow  Address and contact details
Sening
®
is a registered trademark of FMC Technologies
309
Additive Pump
(also called “Dosage Pump” or “Injection Pump”)
No.
Name
Seal
K
Factory
Setting
Meaning
3.3.3
Additive Pump
3.3.3.1
Piston Capacity
Cal.
1
50 (m)
Additive volume per stroke in m .
3.3.3.2
Meter Factor
Cal.
1
1.0
Correction factor of additive pump.
IMPORTANT: Follow chapter 7.2 in setting this
parameter.
3.3.3.3
Pump Position
Cal.
1
1
Injection point of additive pump:
0: No function
1: Before measuring system
2: After measuring system (subject to W & M
inspection!)
3.3.3.4
Hose Volume
Cal.
1
50 (liter)
Volume of measuring system for wet-hose discharge
(measuring system + hose drum) in liters.
3.3.3.5
Ext. Prod. Sensor
M
2
0 (inactive)
Activates monitoring of the filling level on the external
storage tank.
IMPORTANT: The function is currently not
supported.
3.3.3.6
Pump Cycle Time
M
2
6000 (msec)
Maximum time for a pump cycle in msec.
3.3.3.7
Start Interval
Cal.
1
80 (msec)
Minimum dwell time of the piston in the initial position
in msec.
3.3.3.8
End Interval
Cal.
1
80 (msec)
Minimum dwell time of the piston in the end position
in msec.
Form Description
No.
Name
Seal
K
Factory
setting
Meaning
3.4
Form description
3.4.1
Spacing
M
3
1 (characters)
Entry of spacing for the printout in mm or in
characters. Characters is the standard.
3.4.2
Columns Offset
M
3
0
Number of columns before the printout in mm or in
characters. Characters is standard.
3.4.3
Lines Offset
M
3
0
Number of lines before the printout in mm or in
characters. Characters is standard.
3.4.4
ReceiptLayout
M
2
-
Delivery receipt definition, form dialogue.
3.4.5
Print Form
M
Test printout of the delivery receipt.
3.4.6
Form Elements List
M
Printout of defined elements for describing the
delivery receipt.
Product Definition
No.
Name
Seal
K
Factory
Setting
Meaning
3.5
Product Definition
3.5.1
Product Page 1
Product registers 1.1 - 1.0
3.5.2
Product Page 2
Product registers 2.1 - 2.0
3.5.3
Product Page 3
Product registers 3.1 - 3.0
