MultiFlow  Configuration of the MultiFlow
Discharge passes are described by the codes listed in the following table:
Code
Meaning
B
Bypass: Discharge bypassing the overfill prevention system, but limiting the
maximum flow rate to 199  /min (reduced mechanically)
D (L)
Dry Hose: Hose is emptied completely after discharge
P
Dry hose discharge with pump operation
G (S)
Dry hose discharge using gravity
U
Unmetered: Discharge bypassing the meter, no volume is recorded
W (V)
Wet Hose: Discharge through a nozzle, the hose remains filled with product at
any time
 At parameter 3.1.8.7 you enter the required codes reflecting the actual
meter set-up. All codes may be used twice at the most. Also no more than
ten paths may be defined at the most.
Please observe the following rules:
• The abbreviations U, D, G and P may only be used once each.
• The abbreviations V and B may be used twice (always in sequence).
• The abbreviations G and / or P can be used as substitutes for D, but
never together with D (e.g. UVPG or UVD, but not UVDPG).
• No more than ten discharge paths can be defined.
Example: UWWDBB
Meaning: The meter offers the following discharge passes (see
also 321):
1. Unmetered
2. Wet hose 1
3. Wet hose 2
4. Dry hose
5. Bypass 1
6. Bypass 2
The sequence of codes also determines the sequence of the paths
presented to the user in the selection list.
