RUN NOW Excite +: Technical Service guide - rev. 6.2
Page 7.45
Figure 7.21-5
7. Cut the cable-
tie highlight in the figure at the
side, paying attention to not damage the
autotransformer cable.
Figure 7.21-6
CAUTION: Incline the machine on the
left side with caution and protecting it
from the floor.
To make safer the machine in this
position, it is suggested to place some
weight on the handlebar
closer on the
floor.
Figure 7.21-7
8. Back off the 3 screw (g)
using a 5mm
hexagonal wrench.
Continued on following page…
