7. Loosen screw (6) and push the alternator (10) toward
the engine.
8. Remove the fan drive belt (15).
9. Support the alternator (10).
10. Remove screw (7), lock washer (8), and flat washer
(9) from the upper bracket (6) and alternator (10).
11. Remove nut (11), lock washer (12), screw (13), and
flat washer (14), and remove alternator (10).
Installation Notes
• Install the alternator by reversing the order of
removal.
• Adjust fan belt tension. (Refer to “Safety, Operation &
Maintenance Manual”.)
Starter Motor
Removal and Installation
See Figures 4-46 and 4-47.
1. Park the mower safely. (See “Park Mower Safely” on
page 1-5.)
2. Raise the hood.
3. Disconnect the negative (–) battery cable at the
battery.
Figure 4-46
4. Remove the boot (6) from the terminal, and slide it
down the wire (3).
NOTE
Label all wires before disconnecting to ensure correct
installation.
5. Remove nut (7) and lock washer (8), and disconnect
wires (2 and 3) from terminal.
6. Disconnect wiring connector (9) from the starter
motor (1).
7. Support the starter motor (1).
8. Remove screw (4) and lock washer (5).
Figure 4-47
9. Remove socket-head screw (10) and lock washer
(11), and remove the starter motor (12).
Installation Note
Install the starter motor by reversing the order of removal.
